Model - 5107003518
Features
Baked Maple Neck and Fingerboard
The baked maple neck and baked maple fingerboard offer increased stability, crystal clear, bright tones and exquisite style with its warmer hue and beautiful grain definition. Roasting the neck and fingerboard removes moisture from the wood, making it more resistant to humidity shifts and warping.
12"-16" Compound Radius
The innovative 12"-16" compound radius design features a fingerboard that gradually flattens toward the heel from its smaller and more rounded profile at the nut. This makes for unparalleled comfortable chording and riffing near the nut, with optimal shred articulation and bending near the heel.
Direct Mount EVH Wolfgang Humbucking Pickups
Not all humbuckers are created equal. Direct mount EVH Wolfgang humbuckers with Alnico 2 magnets are hotter and harness Eddie’s scorching signature lead tone that captivated the world of rock ‘n’ roll in the ‘70s and ‘80s. These pickups deliver rich harmonics, cutting highs and snarling mids in spades.
EVH-Branded Floyd Rose Special Locking Trem & R2 Locking Nut
Eddie Van Halen was the first player to popularize the innovative Floyd Rose locking tremolo, even advising Floyd Rose on his early designs to integrate round disc finger-type tuners that you would see on a cello or violin. Now universally embraced, our EVH-branded Floyd Rose Special double-locking tremolo features our EVH logo stamped on the bridge plate, zinc alloy saddles and a zinc alloy sustain block. The double-locking design allows you to lock your guitar in tune at the R2 (41.8 mm) nut and at the bridge, resulting in excellent tuning stability and sustain throughout your most aggressive pull-ups and dive bombs.
CONTROLS
SPECS
BODY
- Body Finish Gloss Urethane
- Body Shape Wolfgang®
- Body Material Basswood
NECK
- Neck Material Baked Maple
- Neck Construction Bolt-On with Graphite Reinforcement
- Neck Thickness .790" at 3rd fret & .880" at 12th fret
- Neck Finish Oiled
- Neck Shape Wolfgang® Backshape
- Scale Length 25.5" (64.77 cm)
- Fingerboard Radius 12"-16" Compound Radius (304.8 mm to 406.4 mm)
- Fingerboard Material Baked Maple
- Number of Frets 22
- Fret Size Jumbo
- Nut Material Floyd Rose® R2 Locking
- Nut Width 1.625" (41.3 mm)
- Position Inlays Black Dot
- Side Dots Black
- Truss Rod Nut Heel-Mount Truss Rod Adjustment Wheel
- Truss Rod Wrench 2.5 mm Hex
- String Trees Floyd Rose® Retainer Bar
- Headstock EVH® Wolfgang®
ELECTRONICS
- Bridge Pickup Direct Mount EVH® Wolfgang® Humbucking
- Neck Pickup Direct Mount EVH® Wolfgang® Humbucking
- Pickup Color Black
- Controls Volume with Treble Bleed Circuit, Tone
- Pickup Switching 3-Position Toggle: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup
- Pickup Configuration HH
HARDWARE
- Bridge EVH®-Branded Floyd Rose® Special Locking Tremolo
- Hardware Finish Black
- Tremolo Arm Floyd Rose® Special Locking
- Tuning Machines EVH®-Branded
- Control Knobs Black Plastic with White Indicator
- Switch Tip Black
MISCELLANEOUS
- Strings Nickel Plated Steel (.009-.042 Gauges)
- Strap Buttons Oversized
ACCESSORIES
- Case/Gig Bag Optional EVH® Wolfgang® Hardshell (p/n 009-0916-000); Optional EVH® Black Gig Bag (p/n 022-1512-006)
- Included Accessories Tremolo Arm, Hex Keys & User Manual
