INPUTS
- INPUT impedance 500 Kohm, max. voltage 15 Vpp
- BALANCED INPUT (XLR) impedance 100 Khom, max. voltage 25 Vpp
- EFFECT RETURN impedance 22 Kohm, max. voltage 25 Vpp
- GAIN -80 dB to +23 dB range
- MASTER VOLUME
- GROUND LIFT switch on rear panel
- LOW center frequency: 40 Hz; level: ±16 dB
- LOW MID center frequency: 360 Hz, level: ±16 dB
- HIGH MID center frequency: 800 Hz, level: ±16 dB
- HIGH center frequency: 10 kHz, level: ±16 dB
- VPF (Variable Pre-shape Filter) center frequency 380 Hz (cut)
- VLE (Vintage Loudspeaker Emulator) frequency range 250 Hz-20 kHz (cut)
- LINE OUT balanced XLR, max. voltage 10 Vpp
- EFFECT SEND unbalanced, max. voltage 20 Vpp (pre-EQ)
- TUNER OUT unbalanced, max. voltage 25 Vpp
- SPEAKER OUT speakon, 1/4"
- WEIGHT 5.73 lbs / 2.6 kg
- DEPTH 10.1 in. / 25.6 cm
- WIDTH 10.87 in. / 27.6 cm
- HEIGHT 2.8 in. / 7.1 cm
- OUTPUT POWER 150W RMS 8 ohm, 250W RMS 4 ohm
- POWER REQUIREMENT 100/120V; 230V; 240V 50/60Hz
