SPECS
FREQUENCY RESPONSE
OTHER FEATURES
Phat II EQ
Phat II active bass boost adds additional low-end power.
Jatoba Fretboard
Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
B10 bridge
The B10 bridge allows fully adjustable intonation and solid tuning stability.
- neck type GSR4 Maple neck
- top/back/body Nyatoh body
- fretboard JatobaWhite dot inlay
- fret Medium frets
- bridge B10 bridge
- string space 19mm
- neck pickup Dynamix P neck pickupPassive
- bridge pickup Dynamix J bridge pickupPassive
- equaliser Phat II EQ
- factory tuning 1G,2D,3A,4E
- string gauge .045/.065/.085/.105
- hardware color Black
- Scale : 864mm/34"
- a : Width 41mm at NUT
- b : Width 62mm at 22F
- c : Thickness 21mm at 1F
- d : Thickness 22mm at 12F
- Radius : 305mmR
FREQUENCY RESPONSE
OTHER FEATURES
- Recommended Case MB300C
- Recommended Bag IBB540-BK
Phat II EQ
Phat II active bass boost adds additional low-end power.
Jatoba Fretboard
Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
B10 bridge
The B10 bridge allows fully adjustable intonation and solid tuning stability.
