- Premium series
- Body: Basswood
- Bolt-on neck: Roasted maple
- Fretboard: Roasted maple
- Black dot fretboard inlays
- Neck profile: AZ Oval C (thickness 1st fret 21 mm / thickness 12th fret 23 mm)
- Scale length: 648 mm
- Fretboard radius: 305 mm
- Nut width: 42 mm
- Graph Tech nut
- 22 Jumbo frets
- Pickups: 1 Seymour Duncan Hyperion humbucker (bridge) 2 Seymour Duncan Hyperion single coils (middle and neck)
- 1 x Volume and 1 x tone control
- 5-Way switch
- Alter Switch offers extended pickup combination options
- Gotoh T1502 tremolo
- Gotoh MG-T locking machine heads
- Chrome hardware
- Colour: Black Flat
NECK DIMENSIONS
- Scale : 648mm/25.5"
- a : Width 42mm at NUT
- b : Width 56.4mm at 22F
- c : Thickness 20.5mm at 1F
- d : Thickness 22.5mm at 12F
- Radius : 305mmR
CONTROLS
FREQUENCY RESPONSE
CONTROLS
- Gig bag included
- dyna-MIX9 switching system w/Alter Switch
- Luminescent side dot inlay
- Gotoh MG-T locking machine heads
FEATURES
Luminescent side dot inlay
The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
Gotoh MG-T locking machine heads
The Gotoh MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.
Gotoh T1502 tremolo bridge
T1502 tremolo bridge features steel saddles and a die-cast zinc tremolo block for a quick response and improved articulation. The 10.5mm string spacing allows for easy picking across strings. Its snap-in construction makes it easy to load a tremolo arm.
dyna-MIX 9 switching system w/Alter switch
dyna-MIX 9 offers nine sound variations, and can easily switch between humbucker and single coil modes with just the mini switch. One mode is even able to simulate a humbucker sound from the combination of the 2 single coil pickups.
Seymour Duncan Hyperion Pickups
Seymour Duncan Hyperion Pickups feature a moderate output through Alnico-5 magnets to keep the clarity of the fundamental tone when using a distortion sound, and to deliver a clear pick attack. From treble to bass, the overall tonal balance is evenly adjusted., and works well with various effect pedals.
Roasted Maple fretboard w/Black dot inlay
Heat-treatment provides a well-balanced attack and tone and a rich sustain. In order to achieve supreme neck grip comfort, the fretboard edge is finished with a smooth curve.
AZ Roasted Maple neck
Heat-treatment increases the wood's stability, durability, water resistance and tolerance of temperature changes.
An ergonomic body back contour
A shallow body back contour and a big forearm contour make the guitar body fit the player naturally, thus increasing playing comfort. The AZ body has a deep waist and different radii on each body edge curve, making it easier to play in both standing or sitting positions.
