COLOR VARIATION:Black Ice Burst
Taking adaptability to new extremes, the AZ series has established itself and carved out a place that spans everything from the warmest blues licks, to the most intense, shred-heavy metal riffs. Carrying this ethos forward, the AZ line embodies time-tested Ibanez innovation and player-focused features like a smooth, oval neck grip, a well-balanced asymmetrical body shape, and the neck heel allowing for unrivaled playability.
SPECS
- neck type AZ Oval C Roasted Maple neck
- top/back/body Quilted Maple top American Basswood body
- fretboard Ebony fretboard Mother of Pearl dot inlay
- fret Jumbo Stainless Steel frets
- number of frets 24
- bridge Gotoh® T1502 bridge
- string space 10.5mm
- neck pickup DiMarzio® Air Norton™ (H) neck pickupPassive/Alnico
- middle pickup DiMarzio® True Velvet™ (S) middle pickupPassive/Alnico
- bridge pickup DiMarzio® The Tone Zone® (H) bridge pickupPassive/Alnico
- factory tuning 1E,2B,3G,4D,5A,6E
- strings D'Addario® EXL110
- string gauge .010/.013/.017/.026/.036/.046
- nut Graph Tech® nut
- hardware color Gold
NECK DIMENSIONS
- Scale : 648mm/25.5"
- a : Width 42mm at NUT
- b : Width 57mm at 24F
- c : Thickness 20.5mm at 1F
- d : Thickness 22.5mm at 12F
- Radius : 305mmR
SWITCHING SYSTEM
CONTROLS
OTHER FEATURES
- Recommended Case MR500C
- Gig bag included
- Gotoh® MG-T locking machine heads
- Luminescent side dot inlay
Features
DiMarzio® Air Norton™ / True Velvet™ / The Tone Zone® pickups
The DiMarzio® Air Norton™, True Velvet™ and Tone Zone® pickups offer depth, warmth and rich dynamics when combined with the 5-way pickup switch.
Ebony Fretboard
Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.
Gotoh MG-T locking machine heads
The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.
Oval C Roasted Maple neck
Heat-treatment increases the wood's stability, durability, water resistance and tolerance of temperature changes.
Gotoh T1502 tremolo bridge
The T1502 tremolo bridge features steel saddles and a die-cast zinc tremolo block for a quick response and improved articulation. The 10.5mm string spacing allows for easy picking across strings and its snap-in construction makes it easy to load a tremolo arm.
