COLOR VARIATION : Natural Low Gloss
- body shape Grand Dreadnought body
- bracing X-M Bracing
- top Solid Sitka Spruce top
- back & sides Sapele back & Sapele sides
- neck AADOkoume neck
- fretboard Purpleheart fretboard
- bridge Purpleheart bridge
- inlay White dot inlay
- soundhole rosette Black & White multi rosette
- tuning machine Chrome Die-cast tuners (18:1 gear ratio)
- number of frets 20
- bridge pins Ibanez Advantage™
- strings D'Addario® EXP16
- string gauge .012/.016/.024/.032/.042/.053
- string space 11mm
- factory tuning 1E,2B,3G,4D,5A,6E
- output jack -
- Scale : 650mm/25.6"
- a : Width 43mm at NUT
- b : Width 55mm at 14F
- c : Thickness 21mm at 1F
- d : Thickness 22mm at 7F
- Radius : 400mmR
- a : Length 20 3/8"
- b : Width 16 1/4"
- c : Max Depth 5 "
- Recommended Case FS40DA
- Recommended Bag IAB540-BK
Grand Dreadnought body
Through a rigorous R&D process spanning several years, Ibanez has reimagined the Dreadnought from the ground up, pursuing the height of rich sound, robust low end, and rich tone. This brand new body shape is called the Grand Dreadnought. Proportionally, the Grand Dreadnought body is 5% larger than a standard dreadnought, allowing for more volume, richer tone, and more powerful low end response. It's also extremely comfortable to play thanks to the extensive consideration given to its ergonomics.
After spending years of trial-and-error, Ibanez realized the out-of-the-box X-M Bracing to generate the ultimate sound standing out on the stage. The carefully designed scalloped X-bracing, the allocation of tone braces, and finger braces transmit the string vibration efficiently through the bridge to the body. The X-M Bracing creates the clear bottom and crispy treble sound with trimmed warm mid-range, yet provides a wide dynamic range and high response.
Functional Tapered Headstock
The newly designed headstock shape is the result of thorough research and investigation. Its tapered shape provides lighter weight, as well as a straight string alignment which enhances tuning stability and reduces any neck twisting effect.
Ibanez Advantage bridge pins
These pins really are an advantage over old-fashioned pins. Advantage™ pins are easier to take out and easier to put in than standard pins. A special bulb-shaped end makes the pin easy to grip and also prevents the pin from being pushed in too far. Best of all, with Advantage™ the pin and string stay put.
